Properties of Metal Chrome

Physical Properties of Cr Metal

Appearance: Chromium is a shiny, silvery-white metal.

Density: Approximately 7.19 g/cm3.

Melting Point: Approximately 1907°C.

Boiling Point: Approximately 2671°C.

Hardness: Chromium is an extremely hard metal. Chromium (Cr) > Titanium (Ti) > Nickel (Ni) > Copper (Cu).

Electrical Conductivity: Silver (Ag) > Copper (Cu) > Aluminum (Al) > Tungsten (W) > Chromium (Cr) > Nickel (Ni).

Magnetism: Non-magnetic at room temperature.

Chemical Properties of Cr Metal

Chromium exhibits strong resistance to oxidation and can form a stable chromium oxide (Cr2O3) layer on its surface, which prevents further corrosion.

Production Process of Metal Chrome

The production process of metal chromium involves several methods: the electrolytic method, the aluminothermic method, and the vacuum carbon reduction method. In China, the primary method for producing metal chromium is the aluminothermic method, with a small amount using the electrolytic method.

The natural chromium resources mainly consist of chromite ore. To produce metal chromium, chromium oxide is used as the raw material, which involves two steps. Firstly, chromite ore is used to produce chromium oxide. Then, aluminum is used to reduce chromium oxide (i.e., the aluminothermic method) to smelt metal chromium. The production of chromium oxide from chromite ore involves alkaline roasting, converting insoluble Cr3+ chromium salts into soluble Cr6+ chromium salts, namely Na2CrO4. Chromium oxide is then obtained from the sodium chromate (Na2CrO4) solution. There are three industrial methods for producing chromium oxide from sodium chromate solution:

1. Ammonium chloride reduction method: Sodium chromate (Na2CrO4) is converted into sodium dichromate (Na2Cr2O7) solution by adding sulfuric acid. After concentration, sodium sulfate (Na2SO4) crystals are precipitated. The mother liquor is cooled to 25°C to obtain sodium dichromate crystals. These crystals are mixed with ammonium chloride and reduced at 700-800°C to obtain Cr2O3 and NaCl.

2. Chromium oxide is obtained after washing away NaCl, followed by oxidation calcination at about 1200°C to desulfurize and obtain chromium oxide.Chromic anhydride thermal decomposition method: Sodium dichromate crystals react with concentrated sulfuric acid to produce chromic anhydride (CrO3), which is then thermally decomposed into chromium oxide in a high-temperature calcination furnace.

3. Oxygen chromium thermal decomposition method: Sulfur powder or sodium sulfide solution is added to the sodium chromate solution to reduce Cr6+ to Cr3+, precipitating Cr(OH)3. Chromium oxide is then obtained after high-temperature calcination.

Using the hydroxide method to produce chromium oxide has several advantages, including a short process, high chromium recovery rate, no generation of corrosive gases (beneficial for factory and equipment maintenance), saving a large amount of sulfuric acid and chemical raw materials, the recyclability of by-products such as sodium thiosulfate (Na2S2O3), and cost reduction.

The Production of Chrome Metal

Metal chromium is mainly produced by the aluminothermic reduction of chromium oxide.

The aluminothermic method was the first to be developed. Using this method, approximately 1.6 tons of chromium oxide are required to produce one ton of chromium metal.

The aluminothermic process for manufacturing chromium metal requires chromium oxide, aluminum powder, and additives. Besides chromium metal, the aluminothermic process also produces by-product slag, which can be used to manufacture:

1.Refractory castables and bricks for steel plants, cement kilns, glass production furnaces, and incinerators.

Abrasives.

2.Dry shake floor hardeners.

3.High anti-skid road surface repair agents.

4.Slag additives for stainless steel production.

Applications of Chrome Metal

Chromium, as a brittle metal, cannot be used alone as a metal material. However, when combined with iron, nickel, cobalt, titanium, aluminum, copper, and other metals, it becomes an engineering material with heat resistance, thermal strength, wear resistance, and special properties. Metal chromium is used to produce various high-temperature alloys based on nickel or cobalt, titanium alloys, aluminum-based alloys, resistance alloys, and copper alloys. Some are used to produce stainless steel and heat-resistant steel. These materials are widely used in aerospace, nuclear reactors, automobiles, shipbuilding, chemical industry, military industry, and other fields.

1. Chromium metal used in high-temperature alloys can improve mechanical strength, corrosion resistance, and high-temperature resistance. With these unique properties, when chromium metal is added to superalloys, it can achieve very demanding applications, such as aerospace turbine reactors, land-based gas turbines, petroleum and natural gas industries, medical alloys, nuclear industries, chemical industries, and automotive industries.

2. Chromium metal as a thin film material in the electronics industry also exhibits excellent performance. It becomes crucial in the production of computer hard drives (as both a substrate and a magnetic storage medium component), photomasks, integrated circuits, and LCDs.

3. In the nuclear industry, chromium-containing high-temperature alloys are used to manufacture steam pipes. These pipes are the only interface between the primary and secondary loops in pressurized water reactors. They are exposed to extreme conditions such as constant temperatures exceeding 200°C and high pressure.
